RightMark Audio Analyzer test report

Testing device Угиййф Кпфхоиейн
Sampling mode 24-bit, 44 kHz
Interface
Testing chain External loopback (line-out - line-in)
RMAA Version 6.4.1 PRO


20 Hz - 20 kHz filter ON
Normalize amplitude ON
Level change 0.6 dB / 0.6 dB
Mono mode OFF
Calibration singal, Hz 1000
Polarity correct/correct



Summary

Frequency response (from 40 Hz to 15 kHz), dB
+0.04, -0.31
Very good
Noise level, dB (A)
-119.7
Excellent
Dynamic range, dB (A)
119.5
Excellent
THD, %
0.0004
Excellent
THD + Noise, dB (A)
-96.0
Excellent
IMD + Noise, %
0.0022
Excellent
Stereo crosstalk, dB
-115.8
Excellent
IMD at 10 kHz, %
0.0015
Excellent
General performance

Excellent



Frequency response

Spectrum graph


Left
Right
From 20 Hz to 20 kHz, dB
-0.55, +0.04
-0.58, +0.04
From 40 Hz to 15 kHz, dB
-0.31, +0.04
-0.31, +0.04



Noise level

Spectrum graph


Left
Right
RMS power, dB
-118.8
-117.6
RMS power (A-weighted), dB
-120.0
-119.4
Peak level, dB FS
-100.5
-99.4
DC offset, %
+0.0
+0.0



Dynamic range

Spectrum graph


Left
Right
Dynamic range, dB
+118.5
+117.5
Dynamic range (A-weighted), dB
+119.8
+119.2
DC offset, %
+0.00
-0.00



THD + Noise (at -3 dB FS)

Spectrum graph


Left
Right
THD, %
+0.0004
+0.0004
THD + Noise, %
+0.0015
+0.0015
THD + Noise (A-weighted), %
+0.0016
+0.0016



Intermodulation distortion

Spectrum graph


Left
Right
IMD + Noise, %
+0.0022
+0.0022
IMD + Noise (A-weighted), %
+0.0021
+0.0021



Stereo crosstalk

Spectrum graph


Left
Right
Crosstalk at 100 Hz, dB
-116
-115
Crosstalk at 1000 Hz, dB
-111
-118
Crosstalk at 10000 Hz, dB
-92
-108



IMD (swept tones)

Spectrum graph


Left
Right
IMD + Noise at 5000 Hz,
0.0023
0.0023
IMD + Noise at 10000 Hz,
0.0011
0.0011
IMD + Noise at 15000 Hz,
0.0010
0.0010
